Chocolate Ball Packing Machine
Egg packing machine, the ball packing machine adopt frequency converter technique,easier operation;The part which touches the chocolate are made with food grade material;Packing with high speed,and good appearance.
- The machine is designed according to European standards, the main food contact parts are made of stainless steel material
- The mechanical part and electrical part are separated to ensure high safety requirements
- The advantage of of the machine is stability, high speed, long life.
Character:
- This machine is suitable for automatic processing and packaging of round,spherical, olive, cylindrical chocolate candy;
- Adopt precise high-speed cam transmission mechanism and reasonable mechanical design to improve the production efficiency and stability of the whole machine operation;
- It adopts Panasonic PLC and color code sensor to realize automatic correction of paper, no feeding without material, accurate positioning of color paper pattern and high yield.
Technic Data:
| Chocolate Shape | Ball,Ellipse, egg |
| Diameter of Chocolate | Ball: ¢25mm-28mm Ellipse:L:28mm-30mm,W:22mm |
| Packing Speed | 100pcs/min |
| Packing Material | 45mm wide,0.01-0.04mm thick Alu.Foil |
| Reducer | Main Motor/Brush motor |
| Machine Size | 2183x1380x760mm |
| Weight | 800kg |
| Pressure | 0.6MPa |
Specification:
| Condition | New |
| Applicable Industries | Food & Beverage Factory, Food & Beverage Shops, Chocolate packing plant |
| After Warranty Service | Video technical support, Online support, Spare parts |
| Video outgoing-inspection | Provided |
| Machinery Test Report | Provided |
| Warranty of core components | 1 Year |
| Core Components | PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel |
| Place of Origin | China |
| Voltage | 380v |
| Power | 1.2kw |
| Dimension(L*W*H) | 2183X1380X760mm |
| Weight | 800KG |
| Certification | ISO,CE |
| Warranty | 1 Year |
| Free spare parts | |
| Application fields | Snack food factory, chocolate wrapping plant, Candy packing factory |
| Machinery Function | Ball and Egg chocolate wrapping machine |
| Raw material | Chocolate |
| Output product name | Ball and Egg chocolate |
